Product Summary
The PC357B is a photocoupler.
Parametrics
Absolute maximum ratings: (1)forward current: 50 mA; (2)peak forward current: 1 A; (3)reverse voltage: 6 V; (4)power dissipation: 70 mW; (5)collector-emitter voltage: 35 V; (6)emitter-collector voltage: 6 V; (7)collector current: 50 mA; (8)collector power dissipation: 150 mW; (9)total power dissipation: 170 mW; (10)operating temperature: -30 to +100℃; (11)storage temperature: -40 to +125℃.
Features
Electrical characteristics: (1)forward voltage: 1.2 V typ and 1.4 V max; (2)reverse current: 10 μA; (3)terminal capacitance: 30 pF typ and 250 pF; (4)dark current: 100 nA; (5)collector-emitter breakdown voltage: 35 V; (6)emitter-collector breakdown voltage: 6 V; (7)collector current: 2.5 to 30 mA.
Diagrams
 |
