Product Summary

The AD8052ARM is a low cost, voltage feedback, high speed amplifier which is designed to operate on +3 V, +5 V or ±5 V supplies. It has true single supply capability with an input voltage range extending 200 mV below the negative rail and within 1ÊV of the positive rail.

Parametrics

Absolute maximum ratings: (1)Supply Voltage: 12.6 V; (2)Input Voltage (Common Mode): ±VS; (3)Differential Input Voltage: ±2.5 V; (4)Output Short Circuit Duration: Observe Power Derating Curves; (5)Storage Temperature Range (R): –65℃ to +125℃; (6)Operating Temperature Range (A Grade): –40℃ to +85℃; (7)Lead Temperature Range (Soldering 10 sec): +300℃.

Features

Features: (1)Voltage Feedback Architecture; (2)Fully Specified at +3 V, +5 V and 65 V Supplies; (3)Single Supply Operation: Output Swings to Within 25 mV of Either Rail, Input Voltage Range: –0.2 V to +4 V; VS = +5 V; (4)High Speed and Fast Settling on +5 V: 110 MHz –3 dB Bandwidth (G = +1), 145 V/ms Slew Rate, 50 ns Settling Time to 0.1%.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD8052ARM
AD8052ARM

IC OPAMP VF R-R DUAL LDIST 8MSOP
Data Sheet
0-100: $2.11
AD8052ARM-EBZ
AD8052ARM-EBZ

BOARD EVAL FOR AD8052ARM
Data Sheet
0-1: $14.38
AD8052ARM-REEL7
AD8052ARM-REEL7

IC OPAMP VF R-R DUAL LDIST 8MSOP
Data Sheet
0-1000: $1.44
AD8052ARMZ
AD8052ARMZ

IC OPAMP VF R-R DUAL LDIST 8MSOP
Data Sheet
0-1: $2.50
1-10: $2.23
10-25: $2.00
25-100: $1.83
100-250: $1.65
250-500: $1.48
500-1000: $1.25
1000-2500: $1.19
AD8052ARMZ-REEL7
AD8052ARMZ-REEL7

IC OPAMP VF R-R DUAL LDIST 8MSOP
Data Sheet
0-1000: $1.25
AD8052ARM-REEL
AD8052ARM-REEL

IC OPAMP VF R-R DUAL LDIST 8MSOP
Data Sheet
0-3000: $1.38
