MIC5207-2.5YM5

Low-Noise LDO Regulator, Guaranteed 180mA output, Low dropout voltage, High output voltage accuracy

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.35 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.30~0.35

PartNumber:: MIC5207-2.5YM5

Brand:: Micrel Semiconductor - Micrel | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. ken Skype : vicko-ken's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-15

From Other Seller

Part Number:MIC5207-2.5YM5
US $0.30 - 0.35
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MIC5207-2.5YM5 is an efficient linear voltage regulator with ultra low noise output, very low dropout voltage (typically 17mV at light loads and 165mV at 150mA), and very low ground current (720μA at 100mA output). The MIC5207-2.5YM5 offers better than 3% initial accuracy. Designed especially for hand-held, battery-powered devices, the MIC5207-2.5YM5 includes a CMOS or TTL compatible enable/shutdown control input. When in shutdown, power consumption drops nearly to zero. Key MIC5207-2.5YM5 features include a reference by pass pin to improve its already low-noise performance, reversed battery protection, current limiting, and over temperature shutdown.

Parametrics

MIC5207-2.5YM5 absolute maximum ratings: (1)Supply Input Voltage (VIN): -20V to +20V; (2)Enable Input Voltage (VEN): -20V to +20V; (3)Power Dissipation (PD): Internally Limited (3); (4)Lead Temperature (soldering, 5 sec): 260℃; (5)Junction Temperature (TJ), All except 1.8V: -40℃ to +125℃; 1.8V ONLY: 0℃ to +125℃; (6)Storage Temperature (TS): -65℃ to +150℃.

Features

MIC5207-2.5YM5 features: (1)Ultra-low-noise output; (2)High output voltage accuracy; (3)Guaranteed 180mA output; (4)Low quiescent current; (5)Low dropout voltage; (6)Extremely tight load and line regulation; (7)Very low temperature coefficient; (8)Current and thermal limiting; (9)Reversed-battery protection; (10)Zero off-mode current; (11)Logic-controlled electronic enable.
