LP2981AIM5X-3.0

100 mA, fixed-output voltage regulator, SOT23-5, 16V max, Smallest possible size

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.39~0.43 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.39~0.43

PartNumber:: LP2981AIM5X-3.0

Brand:: National Semiconductor - NS | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. ken Skype : vicko-ken's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-15

From Other Seller

Part Number:LP2981AIM5X-3.0
US $0.39 - 0.43
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LP2981AIM5X-3.0 is a 100 mA, fixed-output voltage regulator designed specifically to meet the requirements of battery-powered applications. Using an optimized VIP(Vertically Integrated PNP) process, the LP2981AIM5X-3.0 delivers unequaled performance in all specifications critical to battery-powered designs. The applications of the LP2981AIM5X-3.0 are Cellular Phone, Palmtop/Laptop Computer, Personal Digital Assistant (PDA), Camcorder, Personal Stereo, Camera.

Parametrics

LP2981AIM5X-3.0 absolute maximum ratings: (1) Storage Temperature Range:-65℃ to +150℃; (2) Operating Junction Temperature Range:-40℃ to +125℃; (3) Lead Temperature (Soldering, 5 sec.):260℃; (4) ESD Rating:2 kV; (5) Power Dissipation:Internally Limited; (6) Input Supply Voltage (Survival):-0.3V to +16V; (7) Input Supply Voltage (Operating):2.1V to +16V; (8) Shutdown Input Voltage (Survival):-0.3V to +16V; (9) Output Voltage (Survival):-0.3V to +9V; (10) IOUT (Survival):Short Circuit Protected; (11) Input-Output Voltage(Survival):-0.3V to +16V.

Features

LP2981AIM5X-3.0 features: (1) Ultra low dropout voltage; (2) Output voltage accuracy 0.75% (A Grade); (3) Guaranteed 100 mA output current; (4) Smallest possible size (SOT-23, micro SMD package); (5) < 1 μA quiescent current when shutdown; (6) Low ground pin current at all load currents; (7) High peak current capability (300 mA typical); (8) Wide supply voltage range (16V max); (9) Fast dynamic response to line and load; (10) Low ZOUT over wide frequency range; (11) Overtemperature/overcurrent protection; (12) -40℃ to +125℃ junction temperature range.
