AD8605ARTZ-REEL7

single, dual, quad rail-to-rail input and output, single-supply amplifier, SOT23-5, 6 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.02~1.16 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.02~1.16

PartNumber:: AD8605ARTZ-REEL7

Brand:: Analog Devices - ADI | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. ken Skype : vicko-ken's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-17

From Other Seller

Part Number:AD8605ARTZ-REEL7
US $1.02 - 1.16
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD8605ARTZ-REEL7 is a single, dual, and quad rail-to-rail input and output, single-supply amplifier. It features very low offset voltage, low input voltage and current noise, and wide signal bandwidth. The AD8605ARTZ-REEL7 uses the Analog Devices, Inc. patented DigiTrim trimming technique, which achieves superior precision without laser trimming. The applications of the AD8605ARTZ-REEL7 include Photodiode amplification, Battery-powered instrumentation, Multipole filters, Sensors, barcode scanners, Audio.

Parametrics

AD8605ARTZ-REEL7 absolute maximum ratings: (1)Supply Voltage: 6 V; (2)Input Voltage: GND to VS; (3)Differential Input Voltage: 6 V; (4)Output Short-Circuit Duration to GND: Observe Derating Curves; (5)Storage Temperature Range: -65℃ to +150℃; (6)Operating Temperature Range: -40℃ to +125℃; (7)Junction Temperature Range: -65℃ to +150℃; (8)Lead Temperature (Soldering, 60 sec): 300℃.

Features

AD8605ARTZ-REEL7 features: (1)Low offset voltage: 65 μV maximum; (2)Low input bias currents: 1 pA maximum; (3)Low noise: 8 nV/√Hz; (4)Wide bandwidth: 10 MHZ; (5)High open-loop gain: 1000 V/mV; (6)Unity gain stable; (7)Single-supply operation: 2.7 V to 5.5 V; (8)5-ball WLCSP for single (AD8605) and 8-ball WLCSP for dual (AD8606).
