Product Summary

The PIC16F887 is designed as one kind of 44-pin, enhanced flash-based 8-bit CMOS microcontroller device that is available in 28-pin PDIP, SOIC, SSOP and QFN packages. The PIC16F887 has a 13-bit program counter capable of addressing a 2K x 14 (0000h-07FFh) for the PIC16F882, 4K x 14 (0000h-0FFFh) for the PIC16F883/PIC16F884, and 8K x 14 (0000h-1FFFh) for the PIC16F886/PIC16F887 program memory space. Accessing a location above these boundaries will cause a wraparound within the first 8K x 14 space. The Reset vector is at 0000h and the interrupt vector is at 0004h.

Parametrics

Absolute maximum ratings: (1)Ambient temperature under bias: -40°C to +125°C;(2)Storage temperature: -65°C to +150°C;(3)Voltage on VDD with respect to VSS: -0.3V to +6.5V;(4)Voltage on MCLR with respect to Vss: -0.3V to +13.5V;(5)Total power dissipation: 800 mW;(6)Maximum current out of VSS pin: 95 mA;(7)Maximum current into VDD pin: 95 mA;(8)Input clamp current, IIK: +/-20 mA;(9)Output clamp current, IOK: +/-20 mA;(10)Maximum output current sunk by any I/O pin: 25 mA.etc.

Features

Features: (1)Interrupt Capability; (2)8-Level Deep Hardware Stack; (3)Direct, Indirect and Relative Addressing modes; (4)Power-Saving Sleep mode; (5)Wide Operating Voltage Range (2.0V-5.5V); (6)Industrial and Extended Temperature Range; (7)Power-on Reset (POR); (8)Power-up Timer (PWRT) and Oscillator Start-up Timer (OST); (9)Brown-out Reset (BOR) with Software Control Option; (10)Multiplexed Master Clear with Pull-up/Input Pin; (11)Programmable Code Protection; (12)Program Memory Read/Write during run time; (13)In-Circuit Debugger (on board); (14)High current source/sink for direct LED drive; (15)Interrupt-on-Change pin; (16)Individually programmable weak pull-ups; (17)Ultra Low-Power Wake-up (ULPWU); (18)Timer2: 8-bit Timer/Counter with 8-bit Period Register, Prescaler and Postscaler.etc.
